Click for larger image and other views Image is representative of the product family. Select individual products in the table below for more specific images and product specifications

How can we improve our images or Product Specifications?

Winters PEM Series Steel Dual Scale Economy Pressure Gauge

Be the first to review this item

Product Specifications
Number of Items
1
Case
Steel
UNSPSC Code
41112412
Brand Name
Winters
Wetted Parts
Brass

This item is no longer available

These items ship for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Wed, Sep 3? Order in-stock items in the next 3 hrs 54 mins and choose One-Day Shipping at checkout.

  • Share
Currently showing 1-20 of 33 Next 13 »
Dial Size Special Features Pressure Range Connection Mount Accuracy Mfr Part # ASIN

The Amazon Standard Item Number (ASIN) uniquely identifies
the item in the AmazonSupply.com (and Amazon) catalog.

Available

If an item is currently out of stock, but has an estimated lead time, you can place an order now and we will ship it as soon as it is available.
You can also order more than we currently have in stock.
Read more about back orders in our help section.

Price
All All All All All All All
Currently showing 1-20 of 33 Next 13 »
1-1/2" 0-100 psi/kpa 0-100 psi/kpa 1/8" Male NPT Bottom Mount +/-3-2-3% PEM1320 B0087UBACM yes $6.84 Buy Options
1-1/2" 0-15 psi/kpa 0-15 psi/kpa 1/8" Male NPT Center Back Mount +/-3-2-3% PEM1399 B0087UBF8G yes $7.89 Buy Options
1-1/2" 0-160 psi/kpa 0-160 psi/kpa 1/8" Male NPT Bottom Mount +/-3-2-3% PEM1321 B0087UBB1W yes $8.44 Buy Options
1-1/2" 0-160 psi/kpa 0-160 psi/kpa 1/8" Male NPT Center Back Mount +/-3-2-3% PEM1421 B0087UBS5Q yes $8.50 Buy Options
1-1/2" 0-200 psi/kpa 0-200 psi/kpa 1/8" Male NPT Bottom Mount +/-3-2-3% PEM1322 B0087UBBQW yes $8.19 Buy Options
1-1/2" 0-30 psi/kpa 0-30 psi/kpa 1/8" Male NPT Bottom Mount +/-3-2-3% PEM1300 B0087UB8S8 Usually ships in 2 to 3 weeks $8.57 Buy Options
2" 0-100 psi/kpa 0-100 psi/kpa 1/8" Male NPT Center Back Mount +/-3-2-3% PEM1406 B0087UBNBU yes $5.97 Buy Options
2" 0-15 psi/kpa 0-15 psi/kpa 1/4" Male NPT Bottom Mount +/-3-2-3% PEM136 B0087UBDAQ Usually ships in 2 to 3 weeks $6.52 Buy Options
2" 0-160 psi/kpa 0-160 psi/kpa 1/4" Male NPT Bottom Mount +/-3-2-3% PEM203 B0087UCJWC yes $6.97 Buy Options
2" 0-160 psi/kpa 0-160 psi/kpa 1/4" Male NPT Center Back Mount +/-3-2-3% PEM1409 B0087UBPWW yes $6.92 Buy Options
2" 0-200 psi/kpa 0-200 psi/kpa 1/4" Male NPT Center Back Mount +/-3-2-3% PEM1410 B0087UBQJY yes $6.60 Buy Options
2" 0-30 psi/kpa 0-30 psi/kpa 1/4" Male NPT Bottom Mount +/-3-2-3% PEM199 B0087UCI8C Usually ships in 2 to 3 weeks $6.97 Buy Options
2" 0-30 psi/kpa 0-30 psi/kpa 1/8" Male NPT Bottom Mount +/-3-2-3% PEM206 B0087UCU9Y Usually ships in 2 to 3 weeks $6.36 Buy Options
2" 0-30 psi/kpa 0-30 psi/kpa 1/4" Male NPT Center Back Mount +/-3-2-3% PEM1403 B0087UBIM4 yes $6.76 Buy Options
2" 0-30"Hg Vacuum/kpa 0-30"Hg Vacuum/kpa 1/4" Male NPT Center Back Mount +/-3-2-3% PEM1428 B0087UC8SM yes $6.66 Buy Options
2" 0-300 psi/kpa 0-300 psi/kpa 1/4" Male NPT Bottom Mount +/-3-2-3% PEM205 B0087UCLLG yes $6.54 Buy Options
2" 0-60 psi/kpa 0-60 psi/kpa 1/8" Male NPT Bottom Mount +/-3-2-3% PEM207 B0087UCUR6 yes $6.63 Buy Options
2-1/2" 0-100 psi/kpa 0-100 psi/kpa 1/4" Male NPT Bottom Mount +/-3-2-3% PEM214 B0087UD2V4 yes $8.88 Buy Options
2-1/2" 0-100 psi/kpa 0-100 psi/kpa 1/4" Male NPT Center Back Mount +/-3-2-3% PEM1439 B0087UCC74 Usually ships in 2 to 3 weeks $8.27 Buy Options
2-1/2" 0-15 psi/kpa 0-15 psi/kpa 1/4" Male NPT Bottom Mount +/-3-2-3% PEM211 B0087UD1S8 yes $8.89 Buy Options

Key Features

  • Brass wetted parts for measuring non-corrosive liquid and gas pressure
  • Circular dial is enclosed in a steel case for corrosion resistance
  • Measures pressure with dual scale (psi/kPa)/(Hg. vacuum/kPa)
  • Display accuracy is + or - 3/2/3% over the entire range of the gauge (ASME B40.100 Grade B)
  • Lower mount or center back male connection with either 1/8" or 1/4" NPT rate

Product Description

The Winters PEM series pressure gauge with brass wetted parts has a circular dial enclosed in a steel case and a male connection, and measures pressure with a dual scale (psi/kPa)/(Hg. vacuum/kPa) with an accuracy of + or - 3/2/3%. The brass wetted parts are for measuring non-corrosive liquid and gas pressure. The black-painted steel case is Ingress Protection certified IP52 for protection against dust or liquids. The circular dial comes in 1.5" (40 mm), 2" (50 mm), 2.5" (63 mm), and 4" (100 mm) diameters. The dial has an aluminum black pointer. The lens for the 1.5", 2", and 2.5"diameter dials is polycarbonate for high impact resistance. The lens for the 4" diameter dial is glass for strength and clarity. The gauge measures pressure with a dual scale of either psi/kPa or Hg. vacuum/kPa. The gauge is accurate to + or - 3/2/3% over the entire range of the gauge, American Society of Mechanical Engineers (ASME) B40.100 Grade B accuracy class. The male connection is mounted on the bottom or center back of the gauge and has either a 1/4" NPT (National Pipe Thread) or 1/2" NPT rate. The bourdon tube is phosphor bronze, the movement is brass, and the welding is silver alloy. The over-pressure limit is 25% of full scale value. The working pressure is a maximum of 75% of full scale value. The operating temperature is -40 to 150 degrees F (-40 to 65 degrees C). This pressure gauge is suitable for plumbing, heating, air conditioning, pneumatic, hydraulic, water tanks, and air compressors.

Pressure gauges are instruments used to measure the pressure of a gas or liquid inside a vessel and, often, to help ensure the optimal amount of pressure for a given application. Pressure gauges can range from everyday instruments, such as those used to measure the air pressure in a car or bicycle tire, to highly accurate gauges used in mechanical and industrial processing. Most often, pressure gauges measure pressure relative to another reference. For instance, gauge pressure measures pressure relative to ambient air. An example of a pressure gauge measuring relative to ambient air is a tire pressure gauge or a blood pressure gauge. Differential pressure is the difference in pressure between two points, such as when measuring liquid flow along various points in a pipeline. An absolute pressure gauge measures pressure relative to a perfect vacuum, such as an atmospheric or barometric pressure gauge. All types of pressure gauges include either a male or a female mount to connect to the vessel where pressure is being measured, and display results on a dial with varying increments of measure across a given range.

Winters Instruments manufactures pressure gauges, thermometers, diaphragm seals, pressure transmitters, and switches. The company, founded in 1953, is headquartered in Toronto, Canada.
