TOGGLER ALLIGATOR A10 Screw Anchor, Plastic, 3/8" Diameter, 1-7/8" Length, #10 to #18 Threads, Pack Of 4

Be the first to review this item

ASIN B0051IBLHC

Specifications for this item
Finish Types
N/A
Material Features
N/A
Part Number
41084
Included Components
Anchors & Screws
Brand Name
TOGGLER
Style Name
Flush-mount
Head Type
N/A
Number of Items
4
Fits Hole Size
3/8 inches
Material Type
Polypropylene (PP)
Thread Coverage
N/A
Outside Diameter
3/8  inches
UPC
036296410841
Minimum Embedment Depth
2.5  inches
Size Name
4 Pack
Manufacturer Series Number
ALLIGATOR A10
EAN
0036296410841
Upper Temperature Range
212  Degrees Fahrenheit
Thread Length
3-1/2  inches
Thread Size
#10 to #18
System of Measurement
Inch
Overall Length
1-7/8  inches
LowerTemperature Range
-20  Degrees Fahrenheit

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Tue, Sep 2? Order in-stock items in the next 1 day 20 hrs 11 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Anchor mounts flush into a wall, ceiling, or floor to securely hold a load in solid concrete, brick, and stone
  • Corrosion-resistant polypropylene body expands and elongates within the mounting material when a screw is inserted to distribute force evenly for a solid grip
  • Made in USA, and includes #14 x 2-1/4" sheet metal screws
  • Ultimate tensile strength is 1,168 lb. in 3,500 psi concrete with a #14 sheet metal screw
  • Use one-fourth or less of listed maximum values for safe working loads (as required by local regulations)

Package Details

Shipping Weight: 0.03 pounds
Package Size: 6.8 x 4 x 0.6 inches

Product Description

The TOGGLER ALLIGATOR A10 flush-mount anchor provides a secure hold in solid concrete, brick, and stone, includes #14 x 2-1/4" sheet metal screws for fastening, and is made in USA. Once inserted flush with the surface of a 3/8" drilled hole in a wall, ceiling, or floor, the anchor accepts an included screw. The fins on the anchor head grip the mounting material to prevent spinning when a screw is inserted. The polypropylene body resists corrosion and expands to fill and mold to a hole when a screw is inserted. This helps distribute the force evenly throughout the anchor's length to help prevent fracture of the mounting material. If using screws other than those supplied, the anchor accepts a #10 to #18 size screw with a thread length at least equal to the thickness of the item being fastened plus 2".

Specifications

Ultimate Tensile Strength Values

AnchorDrill DiameterScrew Description1/2" Drywall3,500 psi Concrete
A5/AF53/16"#8 sheet metal screw57 lb.544 lb.
A6/AF61/4"#10 sheet metal screw69 lb.675 lb.
A8/AF85/16"#12 sheet metal screw85 lb.1,025 lb.
A103/8"#14 sheet metal screwN/A1,168 lb.

Warning: Use one-fourth or less of listed maximum values for safe working loads (as required by local regulations). For more information, see the manufacturer's technical bulletin.

Anchors provide reinforcement to fasteners installed in materials that are considered brittle or have insufficient hold such as drywall, concrete, brick, and stone. Anchors provide support through methods such as expansion from within or behind the substrate, or insertion of adhesive compounds into drilled holes.

TOGGLER Anchor System manufactures wall anchors and toggle bolts. The company, founded in 1968, is headquartered in Norwalk, CT.

What’s in the Box?
  • (4) TOGGLER ALLIGATOR A10 anchors
  • (4) #14 x 2-1/4" sheet metal screws
