Thermo Scientific SP87325 Safe-T SH9 Analog Explosion-Proof Stirring Hot Plate with 9.1" x 9.1" Aluminum Heating Plate, 120V

Be the first to review this item

ASIN B005SVD0SA

Specifications for this item
Overall Height
8.984  inches
Overall Width
10  inches
Part Number
SP87325
Operating Frequency
60  Hz
Item Weight
37 pounds
Brand Name
Thermo Scientific
Capacity
25  pounds
Number of Items
1
Material Type
Aluminum
Wattage
1070  Watts
Temperature Range
+38/220  Degrees Celsius
Size Name
9.1 x 9.1-Inch Aluminum Platform
Current Rating
8.9  Amps
Maximum Stirring Speed
1200  RPM
UNSPSC Code
41113036
Minimum Stirring Speed
60  RPM
Overall Length
12.797  inches
LowerTemperature Range
38  Degrees Celsius

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Tue, Sep 23? Order in-stock items in the next 9 hrs 22 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Temperature range of 38 to 220 degrees C (100 to 428 degrees F) with an accuracy of + or - 2 degrees C (4 degrees F)
  • Cast aluminum top plate for uniform heat distribution and resistance to chipping
  • Analog temperature regulation by thermostat with knob control
  • Speed range of 60 to 1,200 rpm with analog knob control
  • UL listed as safe for Class 1, Group C and D flammable gases or solvent vapors that can produce explosive or ignitable mixtures

Package Details

Shipping Weight: 33.8 pounds
Package Size: 19.1 x 15.7 x 15 inches

Product Description

The Thermo Scientific SP87325 Safe-T SH9 analog stirring hot plate has a 9.1 x 9.1 inch cast aluminum top plate, a temperature range of 38 to 220 degrees C, and an accuracy of + or - 2 degrees C. The cast aluminum top plate provides uniform heat distribution and resistance to chipping. It has analog temperature regulation by thermostat with knob control. A well in the top plate can accommodate a thermometer (sold separately) for precise temperature control. It has a speed range of 60 to 1,200 rpm with analog knob control. The plate has a maximum temperature-limiting thermostat that shuts off the power if the temperature reaches 246 degrees C to prevent overheating. This hot plate is UL listed as safe for Class 1, Group C and D flammable gases or solvent vapors that can produce explosive or ignitable mixtures. Designed for permanent installation, the enameled steel housing has integrated mounting lugs. It comes with 1/2-inch conduit, 18 inches of lead wire, and one 2 × 0.38 inch (5 × 1cm) (W x D) polytetrafluoroethylene-coated stir bar. (W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back.) This stirring hot plate is used to heat glassware and heat and mix liquid solutions for scientific applications.

Specifications
Top plate materialCast aluminum
Temperature range38 to 220 degrees C (100 to 428 degrees F)
Temperature accuracy+ or - 2 degrees C (4 degrees F)
Over-temperature safety246 degrees C (474.8 degrees F)
Speed range60 to 1,200 rpm
Speed stability+ or - 3 rpm
Maximum plate load25lb./11.3kg
Standards metUL/cUL listed; Explosion proof for Class 1, Group C and D atmospheres
Power120V 50/60Hz
Top plate dimensions9.1 x 9.1 inches/23.2 x 23.2cm (W x D)
Overall dimensions8.1 x 10 x 12.8 inches/20.8 x 25.4 x 32.4cm (H x W x D)

H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back.

Laboratory hot plates are electric or gas-fired benchtop appliances that are used to heat glassware or its liquid or solid contents. Stirring hot plates can stir a liquid solution by means of a stir bar that is spun magnetically inside the vessel holding the solution. Hot plates are commonly used in scientific research, clinics, and classrooms.

Thermo Fisher Scientific manufactures analytical instruments, laboratory equipment, consumables, and software under the Thermo Scientific, Fisher Scientific, Barnstead, and Nalgene brands, among others. The company is headquartered in Waltham, MA.

What's in the Box?

  • SP87325 Safe-T SH9 analog stirring hot plate
  • Stir bar
  • 1/2-inch conduit
  • 18 inches of lead wire
  • Instructions
