Tapered Dowel Pins, Stainless Steel 18-8, Plain, Inch
Be the first to review this item
Product Specifications
- Brand Name
- Small Parts
- Material Type
- Stainless Steel 18-8
- System of Measurement
- Inch
These items ship for FREE with 2-Day Shipping on orders over $50. (Details)
Want it delivered on Friday, May 24? Order in-stock items in the next 7 hours 43 minutes and choose One-Day Shipping at checkout.
Key Features
- Used for plates, gauges and tools which require absolute alignment
- Release easily, without galling, particularly in soft plate applications
- Major diameter of the large end is the basis for pin size
- Not for blind holes; a tapered through hole is required
Product Description
Taper Dowel Pins can be used for plates, gauges and tools which require absolute alignment. They release easily, without galling, particularly in soft plate applications. Taper pins have a uniform taper over the pin length with both ends crowned. The major diameter of the large end is the basis for pin size. The diameter at the small end is computed by multiplying the nominal length of the pin by the factor 0.02083 and subtracting the result from the basic pin diameter. The taper of these pins is 0.25 + or -0.006 per foot. These pins are not for blind holes. A tapered through hole is required.
