Shimpo TRC-10 Digital Torque Checker, 0.10 - 10.00Nm Range, LCD Display

Be the first to review this item

ASIN B006C2OEHU

Specifications for this item
Number of Items
1
Range
0.10 - 10.00Nm
Material Type
Aluminum
Part Number
TRC-10
Brand Name
Shimpo
Maximum Measurement
0.10 - 10.00Nm
UNSPSC Code
41111600
Style Name
LCD

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Thu, Jul 31? Order in-stock items in the next 1 hr 50 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • High accuracy +/- 0.5 percent F.S. +/- 1 digit to ensure precise results.
  • Wide torque range 2Nm, 5Nm and 10Nm models to meet a wide variety of applications
  • Test memory one touch operation, stores up to 3000 measurements and resets for next test
  • Durable cast aluminum - heavy duty construction
  • Rechargeable NiMH batteries and 120/240 VAC AC adapter

Package Details

Shipping Weight: 16.35 pounds
Package Size: 16.3 x 12.4 x 6 inches

Product Description

The new Shimpo TRC torque checker is a user friendly instrument for calibrating or measuring torque values. A single button process does it all. Zero, test, store, and repeat. In addition to average, maximum, minimum, and peak values, the TRC features red/green/red LED’s (HI-GO-LO) and audible alarm. It’s wide 3,000 data points storage capacity makes large batch testing possible, insuring overall product quality. The TRC torque checker Is USB capable for easy PC/Software interface. Combined with the free DigiTorque_TRC software, graphical display and statistical analysis are performed and collected automatically. The TRC is a portable device powered with internal rechargeable batteries or through a universal AC adapter/charger. The TRC’s small foot print saves valuable lab space. It’s low profile, (3.82") rugged design, and NIST traceable calibration certificate promotes proper calibration procedures, insuring overall product quality. High accuracy +/- 0.5 percent F.S. +/- 1 digit to ensure precise results. Wide torque range 2Nm, 5Nm and 10Nm models to meet a wide variety of applications. Durable cast aluminum - heavy duty construction. Test Memory One touch operation, stores up to 3000 measurements and resets for next test. Variable units of measures displays torque values in, Lbin, Kgcm, Nm, Ncm. Large digital display provide easy to read L.C.D. PC Output - USB interface with add in "Digitorq TR"” software for Microsoft Excel. Flexible power that allows rechargeable NiMH batteries and 120 / 240 VAC AC adapter. Measuring modes captures average and peak (CCW and CW) torque values. Portable, Small foot print, compact, space saver design.
