Sandvik Coromant WNMG 434-KM 3210 GC3210 Grade, MTCVD Coated, 80 Degree Trigon Shape, KM Chip Breaker, 434 Insert Size, 0.1875" Thickness, 0.063" Nose Radius Carbide Turning Insert (Pack Of 10)

Be the first to review this item


Specifications for this item
Item Shape
Finish Types
Part Number
WNMG 434-KM 3210
Cutting Angle
80  Degrees
Brand Name
Sandvik Coromant
Cut Type
Style Name
Hand Orientation
Compatible Devices
DWLNL 12 4C, DWLNL 16 4D, DWLNR 12 4C, A16T-DWLNL 4, A16T-DWLNR 4, A20T-DWLNL 4, A20T-DWLNR 4, A24T-DWLNL 4, A24T-DWLNR 4, A32U-DWLNL 4, A32U-DWLNR 4, S16T-MWLNL 4, S16T-MWLNR 4, S20U-MWLNL 4, S20U-MWLNR 4, S24V-MWLNL 4, S24V-MWLNR 4
Number of Items
Cutting Direction
Chip Breaker Type
Material Type
0.188  inches
Outside Diameter
0.5  inches
Size Name
WNMG 434
Rake Type
Manufacturer Grade
Corner Radius
0.063  inches

This item is no longer available

This item is NOT eligible for "Free Standard Shipping on orders over $50.00" promotion. (Details)

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List

You can add a description later

Key Features

  • T-Max┬« P, Negative style, double-sided carbide insert. Ideal for external turning, large components, and difficult conditions.
  • Trigon 80 degree turning insert, insert size is 434, no. of edges 6
  • Medium Chipbreaker, Cast Iron Application
  • For best results, use CoroTurn┬« RC rigid clamping system. CoroTurn RC is a top and hole clamping system, and is the first choice when stability and security are essential for productive turning of large components. The system is mostly used for external turning, from finishing to roughing, but also for internal turning, when chip evacuation is good.
  • Multilayer coating combines TiCN, Aluminum Oxide, and TiN excellent for high sped turning of nodular cast iron

Package Details

Shipping Weight: 0.15 pounds
Package Size: 3.5 x 1.5 x 0.4 inches

Product Description

KM medium chipbreaker cast iron insert type. CVD-coated carbide consisting of a thick, smooth, wear resistant coating and a very hard substrate. Recommended for high sped turning of nodular cast iron (NCI).
