Click for larger image and other views Image is representative of the product family.

How can we improve our images or Product Specifications?

Prince A400160ABACA07B Double-Acting Tie-Rod Hydraulic Cylinder, Clevis Mounting, Painted, 4" Bore, 16" Stroke, 1-3/4" Rod Diameter, 3/4"-16 Thread, #8 SAE Port

Be the first to review this item

ASIN B005CWJ1ME

Product Specifications
Mfr Part #
A400160ABACA07B
Number of Items
1
Port Size
#8 SAE
Max Pressure
3000  PSI
Upper Temperature Range
180  Degrees Fahrenheit
Bore Diameter
4  inches
Color Name
Black
Overall Height
5  inches
Overall Width
5  inches
Pin Hole Diameter
1  inches
Retracted Length
31.5  inches
Rod Diameter
1-3/4  inches
Stroke Length
16  inches
Thread Size
3/4"-16
Specification for this product family (See all  products)
Exterior Finish
Painted
Item Shape
Tie-Rod
Mounting Type
Clevis Mounting
Seal Material Type
Urethane
Connector Type
UNF
UNSPSC Code
27121602
Brand Name
Prince Manufacturing
System of Measurement
Inch

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Tue, Oct 28? Order in-stock items in the next 1 day 13 hrs 7 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Actuator for converting hydraulic power into mechanical motion
  • High strength tie-rod for large loads
  • Ductile iron piston, butt, gland, and clevis for strength and durability
  • RoyalPlate Plus surface plating for resistance to corrosion
  • Maximum operating pressure of 3,000 psi

Package Details

Shipping Weight: 65 pounds
Package Size: 38 x 6 x 6 inches

Product Description

This Prince tie-rod hydraulic cylinder is an actuator for converting hydraulic power into mechanical motion. It is a double-acting cylinder with two hydraulic ports for both extension and retraction of the rod. The ports are Society of Automotive Engineers (SAE) size 8. It has clevis mounts on both ends with Unified Fine Thread (UNF) threading. It has a high strength tie-rod for large loads, and the piston, butt, gland, and clevis are made of ductile iron for strength and durability. It has RoyalPlate Plus surface plating for resistance to corrosion. This hydraulic cylinder has a maximum operating pressure of 3,000 pounds per square inch (psi).

Linear motion actuators are independent units that, when combined with a switch and power source, push or pull loads in a straight line. Actuator types (mechanical, hydraulic, pneumatic, piezoelectric, electro-mechanical, and telescoping) vary and their application is determined by the power source available, as well as the load and space requirements. Linear motion actuators are used in a variety of applications, such as computer disk drives, deck and implement lifts for tractors, wheelchair lifts on a vehicle, and flow control mechanisms, such as flood gates on a dam.

Prince Manufacturing builds hydraulic cylinders, valves, and pumps. The company, founded in 1941, is headquartered in North Sioux City, SD.
