Opto 22 SNAP-PAC-R2-W - Wired+Wireless SNAP PAC R-series Rack-mounted Programmable Automation Controller, Analog/Digital/Serial I/O Processing

Be the first to review this item

ASIN B0058UW1S6

Specifications for this item
Number of Items
1
Part Number
SNAP-PAC-R2-W
Torque
0.9  Newton Meters
Temperature Range
0 to 60  Degrees Celsius
Brand Name
Opto 22
Upper Temperature Range
60  Degrees Celsius
UNSPSC Code
39121552

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Tue, Nov 25? Order in-stock items in the next 18 hrs 34 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Rack-mounted industrial controller with I/O processor included
  • Two independent 10/100 Mbps Ethernet network interfaces plus 802.11a, b, or g wireless LAN interface; communicate wirelessly, over a wired network, or both simultaneously
  • One RS-232 port with handshaking, suitable for modem communication using PPP; MicroSD card slot for removable data storage
  • Simple digital functions (no high-speed digital)
  • Full-featured control and HMI software included with purchase

Package Details

Shipping Weight: 0.75 pounds
Package Size: 7.3 x 6.4 x 3.7 inches

Product Description

The SNAP-PAC-R2-W offers all the same functionality as a SNAP-PAC-R2, and it adds wireless LAN communication capability as well. This rack-mounted programmable automation controller provides control, communication, and I/O processing in a compact package. One of four components of the SNAP PAC System, the SNAP-PAC-R2-W is fully integrated with PAC Project software, SNAP PAC brains, and SNAP I/O modules. Used with the included PAC Project Basic software suite (or PAC Project Professional, purchased separately), the Ethernet-based SNAP-PAC-R2-W can handle almost all your industrial control, remote monitoring, and data acquisition needs. This intelligent, flexible PAC can be used in several ways. The SNAP-PAC-R2-W can provide complete cell control on its own rack with I/O modules. It can also control SNAP PAC I/O units at the same time for a larger system. Or the R1 can be used in a more extensive distributed control system as an I/O unit controlled by a SNAP PAC S-series standalone controller. It can even be used as intelligent remote I/O for Allen-Bradley PLC systems, such as ControlLogix and MicroLogix. The SNAP-PAC-R2-W includes a wireless LAN interface that supports 802.11a, b, and g network standards. The controller can be used in infrastructure or ad-hoc mode. For security, 802.11i standards are supported, including WPA2-AES as well as WPA and WEP for backwards compatibility. In addition, the controller has an RS-232 serial port with hardware handshaking, which can be used for PPP (Point-to-Point Protocol) communication over a modem or for direct connection to serial devices. The controller mounts on a SNAP PAC mounting rack with up to 4, 8, 12, or 16 digital, analog, and serial SNAP I/O modules. Choose the modules needed for your application from the extensive line of SNAP I/O modules.

IEC 950: 1991-09, 89/336/EEC, 2002/95/EC, Defense Federal Acquisition Regulation Supplement
