Omron G3NA-210B-AC100-120 Solid State Relay, Zero Cross Function, Yellow Indicator, Photocoupler Isolation, 10 A Rated Load Current, 24 to 240 VAC Rated Load Voltage, 100 to 120 VAC Input Voltage

Be the first to review this item

ASIN B003B3F742

Specifications for this item
Number of Items
1
Part Number
G3NA-210B-AC100-120
Brand Name
Omron
Size Name
Photocoupler Isolation
EAN
4536854807909
Style Name
10 A Rated Load Current, 24 to 240 VAC Rated Load Voltage, 100 to 120 VAC Input Voltage
UNSPSC Code
39122300

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Wed, Jul 23? Order in-stock items in the next 7 hrs 49 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Solid state relay for high-speed switching in low current applications
  • Screw terminals for connecting to contacts
  • Noise suppression activated when the load current rises suddenly
  • Indicator for alerting users to operating status
  • UL listed for safety, CSA certified for quality assurance

Package Details

Shipping Weight: 0.1 pounds
Package Size: 3 x 2.3 x 1.8 inches

Product Description

This Omron G3NA-210B-AC100-120 solid state relay has a zero cross function, a built-in operation indicator, photocoupler isolation, and is suitable for high-speed switching in low current applications. It has a load voltage rating of 24 to 240 VAC, a load current rating of 10 amp, and an input of 100 to 120 VAC. This relay has screw terminals for connecting to contacts and zero cross functionality to reduce noise generated when the load current rises suddenly. The photocoupler component isolates the input and output signals by transferring the input signal using light, preventing high voltages from affecting the signal. It has a built-in operation indicator to alert users to the operation status of the relay. This solid state relay is suitable for use with industrial controls and commercial cooking applications.

Specifications
Contact formSPST NO
IsolationPhotocoupler
Load current rating10 amp
Load voltage rating24-240 VAC
Operating temperature-30 to +80 degrees C
Dimensions*58 x 43 x 30 mm (H x W x D)
Standards metUL (Underwriters Laboratories)
CSA (Canadian Standards Association)
RoHS (Restriction of Hazardous Substances)

*H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back.

Relay switches (also called an electrical relay or an electrical relay switch) use a small amount of power to control a larger source of power connected to electrical devices such as car motors, computers, and lighting installations. A basic relay switch has a control circuit with an electromagnetic coil and a load circuit with contacts and a lever. When current flows into the relay switch, it moves through the coil and a magnetic field is created, which causes the lever in the load circuit to move between contacts, either turning the device on or off. In a normally open (NO) relay switch, when power is supplied to the relay, the load circuit is closed and the power source connected to the relay is turned on. In a normally closed (NC) relay switch, when power is supplied to the relay, the load circuit is open and the power source connected to the relay is turned off. In other types of relay switches, non-moving parts such as transistors or semiconductors can be used as the control circuit to operate the switching mechanism. Relay switches can be controlled with an external switch, such as a light switch, or they can be connected to an automatically switched power source, such as a car ignition. One relay can operate multiple switches, and multiple relays can be operated with a single switch, with each relay operating independently from the other relays in the system.

Omron manufactures and distributes electronic components, equipment, and systems for industrial automation. The company, founded in 1933, is headquartered in Kyoto, Japan.
