Milwaukee Valve BB2-350 Series Bronze Butterfly Valve, Unibody, Stainless Steel 304 Disc, Lever Handle, Solder End
Be the first to review this item
Product Specifications
- Brand Name
- Milwaukee Valve
- Connector Type
- Solder End
- Construction Type
- Full Port
- Handle Type
- Lever Handle
- Internal Packing Material Type
- Nylon
- LowerTemperature Range
- 30 Degrees Fahrenheit
- Manufacturer Series Number
- BB2-350
- Material Type
- Bronze
- Maximum Pressure
- 175 PSI
- Seal Material Type
- Viton
- Specification Met
- WW-V-1967
- Structure Description
- Unibody
- Style Name
- Solder
- Upper Temperature Range
- 275 Degrees Fahrenheit
These items ship for FREE with 2-Day Shipping on orders over $50. (Details)
Want it delivered on Tuesday, May 21? Order in-stock items in the next 2 days 11 hours 55 minutes and choose One-Day Shipping at checkout.
Key Features
- Made of bronze for higher strength and corrosion resistance than brass
- Full port for higher operating efficiency and decreased friction than standard ports
- 175 pounds per square inch (psi) rating for water, oil, and gas (WOG)
- Unibody (one-piece construction) valve for reduced possibility of valve leakage
- Solder connections on both ends for a semi-permanent connection to tubing
Product Description
The Milwaukee Valve BB2-350 series unibody butterfly valve is made of bronze with a stainless steel 304 disc, and it has a lever handle and solder connections on both ends. This bronze valve, which is higher strength and more corrosion resistant than brass, is full port for reduced friction; its inner diameter is the same as the inner diameter of the pipe it connects to enable maximum operating efficiency. The one-piece construction reduces the possibility of leakage and it has solder end connections for a semi-permanent yet reversible connection to tubing. The maximum pressure is 175 pounds per square inch (psi) for use with water, oil, and gas (WOG), and the working temperature range is 30 to 275 degrees F. The zinc-plated steel lever handle with a vinyl sleeve rotates the stainless steel 304 disc in the valve seat to fully open, throttle, or stop flow through the valve. This valve is for use with gas, air, and oil systems, and both liquid and vacuum service applications.
Butterfly valves are used to regulate flow between pipes, tubes, and hoses by rotating a lens-shaped disc in the center of the valve and are suited for high-capacity, low-pressure applications. When the valve is fully opened, the disc face is parallel to the inlet and outlet of the valve, and when the valve is closed, the disc face is perpendicular to the opening of the valve. Butterfly valves may have a handle or lever that aligns with the disc position (open or closed) for manual flow control. They are primarily used in applications including agriculture, water treatment, fire protection, compressed air or gas, and vacuum service.
The Milwaukee Valve Company manufactures manual and actuated valves, controls, and control accessories. The company, founded in 1901, and headquartered in New Berlin, WI, meets International Organization for Standardization (ISO) 9001:2008 and 14001:2004 standards.
