Melin Tool AMGS Carbide Square Nose End Mills, Inch, Stub Length, Uncoated (Bright) Finish, 30 Degree Helix, For Use With Cast Iron, Nickel/Nickel Alloys, Plastics, Steel/Steel Alloys, Titanium/Titanium Alloys

Be the first to review this item

Product Specifications
Cutting Direction
Right Hand
Specific Uses For Product
Profile Milling , Slot Milling
Finish Types
Uncoated (Bright)
End Cut Type
Center Cutting
Material Type
Carbide
Cutting Angle
30  Degrees
Brand Name
Melin Tool
Manufacturer Series Number
AMGS
Compatible Material
Cast Iron, Nickel/Nickel Alloys, Plastics, Steel/Steel Alloys, Titanium/Titanium Alloys
Shank Type
Round
Cut Type
General Purpose
UNSPSC Code
27112803
System of Measurement
Inch

This item is no longer available

These items ship for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Tue, Nov 25? Order in-stock items in the next 1 day 17 hrs 12 mins and choose One-Day Shipping at checkout.

  • Share
Currently showing 1-15 of 15
Cutting Diameter Shank Width Cutting Length Overall Length Number of Flutes Mfr Part # ASIN

The Amazon Standard Item Number (ASIN) uniquely identifies
the item in the AmazonSupply.com (and Amazon) catalog.

Available

If an item is currently out of stock, but has an estimated lead time, you can place an order now and we will ship it as soon as it is available.
You can also order more than we currently have in stock.
Read more about back orders in our help section.

Price
All All All All All
Currently showing 1-15 of 15
1/32" 0.0313" 0.0625" 1.5000" 2 16146 B0083JXJJY Usually ships in 4 to 7 weeks $11.23 Buy Options
3/64" 0.0469" 0.0938" 1.5000" 2 16147 B0083JXSAY yes $11.07 Buy Options
1/16" 0.0625" 0.125" 1.5000" 2 16148 B0083JXOXK yes $9.08 Buy Options
5/64" 0.0781" 0.125" 1.5000" 2 11517 B0083JXPTI yes $9.14 Buy Options
3/32" 0.0938" 0.1875" 1.5000" 2 16149 B0083JXR7I yes $8.83 Buy Options
1/8" 0.1250" 0.25" 1.5000" 2 16150 B0083JXNRW yes $8.46 Buy Options
5/32" 0.1563" 0.3125" 1.5000" 2 16151 B0083JXVKQ yes $11.62 Buy Options
3/16" 0.1875" 0.375" 1.5000" 2 16152 B0083JXUQ6 yes $11.18 Buy Options
7/32" 0.2188" 0.5" 2" 2 16153 B0083JXMJQ yes $14.41 Buy Options
1/4" 0.2500" 0.5" 2" 2 16154 B0083JXKHA yes $13.16 Buy Options
5/16" 0.3125" 0.5" 2" 2 16155 B0083JXLJM yes $19.66 Buy Options
3/8" 0.3750" 0.625" 2" 2 16156 B0083JXXOK yes $23.27 Buy Options
7/16" 0.4375" 0.625" 2.5000" 2 16157 B0083JXYFI yes $26.69 Buy Options
1/2" 0.5000" 0.625" 2.5000" 2 16158 B0083JXWIW yes $33.15 Buy Options
5/8" 0.6250" 0.75" 3" 2 16159 B0083JXTFS yes $55.18 Buy Options

Key Features

  • Solid carbide tools offer long tool life and faster cutting speeds than other substrates, but are more brittle and must be used with rigid toolholding systems
  • Uncoated tools feature just the base substrate without any additional treatment or coatings and are suitable for a wide range of applications
  • Round shanks allow use with a wide variety of toolholding systems
  • Used for general purpose milling in most materials of medium hardness such as steel, brass, iron, and non-ferrous materials
  • 30 Degree helix angle

Product Description

Solid carbide tools offer long tool life and faster cutting speeds than other substrates, but are more brittle and must be used with rigid toolholding systems. Uncoated tools feature just the base substrate without any additional treatment or coatings and are suitable for a wide range of applications. Round shanks allow use with a wide variety of toolholding systems. Used for general purpose milling in most materials of medium hardness such as steel, brass, iron, and non-ferrous materials. 30 Degree helix angle. Stub length.
