Mason HD-B-RED Rubber Double Deflection LDS Hanger Vibration Isolator for Rod Attachment, 235lbs Capacity, 0.40" Deflection, Red

Be the first to review this item

ASIN B006W0QG8W

Specifications for this item
Number of Items
1
Material Type
Rubber
Part Number
HD-B-RED
Brand Name
Mason
Load Capacity
235  pounds
List price:
$36.00
Price:
$28.54
You save:
$7.46 (21%)
Quantity:

In Stock (17)

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Fri, Apr 18? Order in-stock items in the next 17 hrs 31 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Double deflection LDS rubber element with a projecting bushing to prevent steel to steel contact
  • Molded in LDS because of its excellent aging characteristics
  • Hanger elements have straight line deflection curves
  • HD Hangers are double deflection units with average static deflections of 0.35"
  • Measures 4-1/4" width by 4-1/2" height by 3-1/4" depth

Package Details

Shipping Weight: 1.6 pounds
Package Size: 5.3 x 4 x 2.5 inches

Product Description

HD Hangers are double deflection units with average static deflections of 0.40". Double deflection LDS rubber element with a projecting bushing to prevent steel to steel contact. They are molded in LDS because of its excellent aging characteristics. If you wish to isolate primary vibration, they should only be considered for smaller equipment running above 800 RPM in non-critical areas. The principle function of HD Hangers is noise isolation. 50 Durometer, 3" Lower rod penetration. 3/4" Maximum rod diameter. 0.40" Maximum rated deflection. Vertical G rating tension: 10.0+. Vertical G rating compression: 10.0+. Measures 4-1/4" width by 4-1/2" height by 3-1/4" depth.
