Ken-A-Vision T-19011C Comprehensive Scope 2 with Cordless Monocular Compound Microscope, 10× Eyepiece

Be the first to review this item

ASIN B005KC4OQE

Specifications for this item
Number of Items
1
Overall Height
14  inches
Overall Width
7  inches
Part Number
T-19011C
UPC
012345678912
Brand Name
Ken-A-Vision
Size Name
4×, 10×, 40×S, 100×S DIN achromat objective lenses
EAN
0012345678912
UNSPSC Code
41111709
Overall Length
10  inches

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Tue, Dec 23? Order in-stock items in the next 9 hrs 45 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Compound microscope provides high magnification for biological use and educational applications
  • Monocular viewing head with fixed 30-degree vertical inclination, and 360-degree rotation capability
  • 10x eyepiece with reverse-mounted 3-position stop and 4x, 10x, and 40xS lens objectives
  • Bright and cool LED white light with dimmer and on/off switch, and 5-hole disc diaphragm
  • Cordless microscope has a built-in rechargeable NiMH battery

Package Details

Shipping Weight: 10.95 pounds
Package Size: 20 x 15.8 x 9.8 inches

Product Description

The Ken-A-Vision T-19011C Comprehensive Scope 2 cordless, monocular compound microscope has LED lighting with dimmer control (rheostat) and on/off switch, a 10x widefield eyepiece with reverse-mounted 4x, 10x, and 40xS lens objectives, and is designed for biological use and educational applications. The monocular head has a fixed 30-degree incline and 360 degree rotation for comfortable viewing and a total magnification up to 400x. Separate knobs for coarse and fine focus provide sharp focus. The fixed, plain stage has clips to hold the slide in place and rack-and-pinion movement. The built-in bright and cool white LED light has a dimmer control (rheostat) with a separate on/off switch to control the amount of light projected on the specimen. The single-cast aluminum body has a built-in, retractable, carrying handle for strength and durability. A built-in rechargeable NiMH battery (included) enables the microscope to be used away from power sources. The microscope includes an allen wrench, cover, power supply, and instructions.

Specifications
Eyepiece 10x widefield
Objective lenses 4x, 10x, 40xS, DIN achromatic
Viewing configuration Monocular with 30 degree incline and 360 degree rotation
Nosepiece Reverse 3-hole with three-position ball-bearing stop and 360 degree rotation
Illumination Bright and cool LED white light with dimmer control (rheostat) and on/off switch
Focus Coarse and fine
Stage Fixed plain stage with slide clips and 5-hole disk diaphragm
Housing construction Single-cast aluminum
Illumination power source Low voltage external power supply 120-240V 50/60 H2 0.2A ± DC 7.5V 800mA, with rechargeable battery
*Overall dimensions 50.8 x 33.02 x 40.64 cm/20 x 13 x 16 inches
Weight 6.4kgs/14lbs
Certificates ISO:9001 – 2000, CE, CSA, RoHS

*H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back.

Microscopes are instruments used to enhance the resolution of an object or image. Types include compound, stereo, or digital. Compound microscopes use a compound optical system with an objective lens and an eyepiece. Stereo microscopes show object depth in a three-dimensional image. Digital microscopes are used to display an image on a monitor, rather than looking through a lens. Microscopes can have monocular (one), binocular (two), or trinocular (three) eyepieces, with varying magnification abilities. Magnification ability refers to the size of an image. Resolution, also known as resolvant power, refers to the clarity of the image. The interaction between field of view (FOV), numerical aperture (NA), and working distance (WD) determines resolution. Microscopes can control magnification through a fixed focus, or through a range of adjustments. They can also utilize LED, fluorescent, and mirror light sources to help control viewing capabilities. Microscopes are widely used in education, lab research, biology, metallurgy, engineering, chemistry, manufacturing, and in the medical, forensic science, and veterinary industries.

Ken-A-Vision Manufacturing, founded in 1957 and headquartered in Kansas City, MO, manufactures educational products such as microscopes, cameras, and software.

What’s in the Box?
  • Ken-A-Vision T-19011C cordless microscope
  • Allen wrench
  • Microscope cover
  • Power supply
  • Instructions
