R&M Hoists RL EZ Lift Lever Hoist, Single Fall, Hook Mount, 3 Ton Capacity, 5' Lift, Headroom, 16.46" Lever Length, 1.575" Hook Opening

Be the first to review this item

ASIN B004OR1FB8

Specifications for this item
Number of Items
1
Maximum Lifting Height
5  feet
Material Type
Steel
Part Number
2104335005
Inside Width
1.575  inches
Brand Name
R&M Hoists
Size Name
88 pounds
Manufacturer Series Number
RL EZ Lift
Specification Met
ASME B30.21
Mounting Type
Hook
Load Capacity
6000  pounds
UNSPSC Code
24101602
Overall Length
16.46  inches

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Mon, Aug 25? Order in-stock items in the next 1 day 3 hrs 24 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Manual lever hoist with hook mount, chrome-finished steel construction for strength and resistance to wear, and galvanized grade 80 alloy steel load chain for strength and resistance to corrosion
  • Handle with 360-degree rotation for working in tight spaces, and a rubber grip to minimize slip
  • Heat-treated, alloy steel mount hook and load hook with forged inspection points for strength, and to facilitate inspection
  • Mechanical friction disk brake with four braking surfaces, covered for protection from dirt
  • Complies with ANSI/ASME B30.21 standards

Package Details

Shipping Weight: 53.9 pounds
Package Size: 22.3 x 9.6 x 8.8 inches

Product Description

The R&M Hoists RL EZ Lift lever hoist is a manually operated hoist with a hook mount, chrome-finished steel and a galvanized grade 80 alloy steel load chain for strength and resistance to wear. The lever handle on this hoist rotates 360 degrees for working in tight spaces, and has a rubber grip to minimize slip. This hoist has a heat-treated alloy steel mount hook and load hook with inspection points for strength, and to facilitate periodic inspections as described in the owner’s manual. The RL EZ Lift lever hoist has a Weston-style mechanical friction disk brake with four braking surfaces that is covered for protection from dirt. This hoist is used in the construction, manufacturing, and mining industries to lift, lower, and move items, and can be employed for similar purposes in other industries. The RL EZ Lift lever hoist is produced to comply with American National Standards Institute/American Society for Mechanical Engineers (ANSI/ASME) B30.21 standards.

Capacity is the maximum rated load a hoist can handle. While manufacturers may indicate they have tested a hoist beyond its limits, operators should never attempt to lift a load heavier than the maximum rated load. Pull force describes the amount of force that needs to be applied to lift a load. If a 1/2 ton manual hoist specifies a pull force of 40 lbs., for example, the operator needs to be able to pull a 40 lb. weight in order to lift the maximum 1/2 ton (500 lb.) load. Headroom is the distance from the bottom of the load hook to the top of the hoist. This is the minimum amount of vertical space needed for the hoist to hang freely and operate correctly. Lift is the maximum vertical distance the load hook can move a load.

Hoists are devices that use relatively small amounts of force to lift, lower, and pull heavy loads. Manual hoists transfer a small, hand-exerted force either across a series of gears to multiply the force into one large enough to lift the designated load, or over a pulley, drum, or sheave to leverage the force into one strong enough to lift the load. This makes it possible for an operator to manage heavy loads. The manual force is usually applied using a hand chain, lever, or lever ratchet, lifting the load by a hook attached to a chain, rope, or wire. Hand chain and lever hoists commonly use mechanical disk brakes called Weston-style brakes that hold the load in place while the operator’s hands are released to make the next pull, secure the load once it has been lifted, and control the descent of the load as it is lowered. Ratchet puller hoists commonly use ratchets instead of mechanical brakes to secure and control the load. Manual hoists are commonly attached to or suspended from structures by hook or trolley mounts, and are used in the transportation, construction, manufacturing, mining, and material handling industries, among others.

R&M Materials Handling, Inc. manufactures hoists, crane components, and crane accessories. The company, founded in 1929, is based in Springfield, OH.
