Ham-Let H1200 Series Brass Toggle Valve, Inline, 1/8" Let-Lok Fitting
Be the first to review this item
ASIN B006GWP4IY
Specifications for this item
- Ball Material Type
- Brass
- Brand Name
- Ham-Let
- Connection Size
- 1/8"
- Connector Type
- Let-Lok Compression
- End-to-End Length
- 1.96 inches
- Item Shape
- Inline
- LowerTemperature Range
- -200 Degrees Fahrenheit
- Manufacturer Series Number
- H1200 Series
- Material Type
- Brass
- Maximum Pressure
- 300 PSI
- Mfr Part #
- 3300283
- Number of Items
- 1
- Operation Mode
- Spring Return
- Seat Material Type
- PTFE
- Style Name
- Compression
- System of Measurement
- Inch
- Upper Temperature Range
- -20 Degrees Fahrenheit
This item ships for FREE with 2-Day Shipping on orders over $50. (Details)
Want it delivered on Friday, May 24? Order in-stock items in the next 23 hours 1 minute and choose One-Day Shipping at checkout.
Key Features
- Compact Rugged Design
- Brass Construction
- Panel Mountable
- Quick On/Off Service
- MAWP 300 psig at 20°C (70°F)
Package Details
Shipping Weight:
0.25 pounds
Package Size:
3.2 x 2.3 x 2 inches
Product Description
The H-1200 Series standard toggle valve is a compact design for normally closed and quick on/off service. Moving the handle 90 degrees upwards opens the valve to full flow and stops it firmly in the open position. Shifting the handle position downwards shuts off the valve by spring return. The PTFE soft seat at the tip of the stem provides a positive repetitive seal.
