Steel Hex Bolt, Grade 5, Zinc Plated Finish, Serrated, Flange Hex Head, External Hex Drive, Meets IFI 111/SAE J429, Flanged, Serrated, 2-1/2" Length, Fully Threaded, 1/4"-20 UNC Threads, Imported (Pack of 25)
Be the first to review this item
ASIN B006HYDV7M
Specifications for this item
- Brand Name
- Small Parts
- Drive Style
- External Hex
- Exterior Finish
- Zinc Plating
- Flange Thickness
- 0.04 inches
- Head Diameter
- 3/8 inches
- Head Height
- 9/32 inches
- Head Style
- Flange Hex
- Length
- 2-1/2 inches
- Material Type
- Steel
- Part Number
- B006HYDV7M
- Pkg Qty
- 1
- Size
- 1/4"
- Specification Met
- IFI 111 , SAE J429
- Style Name
- Serrated
- System of Measurement
- Inch
- Tensile Strength Max
- 120000 PSI
- Thread Class
- 2A
- Thread Coverage
- Fully Threaded
- Thread Size
- 1/4"-20
- Thread Style
- UNC
- Thread Style
- Right Hand
This item ships for FREE with 2-Day Shipping on orders over $50. (Details)
Want it delivered on Friday, June 21? Order in-stock items in the next 9 hours 11 minutes and choose One-Day Shipping at checkout.
Package Details
Shipping Weight:
0.9 pounds
Package Size:
4.9 x 4.1 x 1.1 inches
