3D CAD Models (Which File Type?)
Friction Hinge, 304 Stainless Steel, 1-49/64" Leaf Height, 1-47/64" Open Width, 21.7 lbs/in Torque (Pack of 1)
Be the first to review this item
ASIN B005P0G360
Specifications for this item
- Brand Name
- Sugatsune
- Exterior Finish
- Polished
- Material Type
- Stainless Steel 304
- Mounting Hole Diameter
- 4.3 millimeters
- Number of Items
- 1
- Overall Height
- 1-49/64 inches
- Overall Width
- 1-47/64 inches
- Part Number
- HG-ITS25
- Size Name
- 21.7 in-lbs
This item ships for FREE with 2-Day Shipping on orders over $50. (Details)
Want it delivered on Thursday, June 20? Order in-stock items in the next 18 hours 10 minutes and choose One-Day Shipping at checkout.
Key Features
- Pin material: 303 Stainless Steel
- Number of holes: 6
- With hole: Yes
- Body material: 304 stainless Steel
- Screw type: 4.3mm
Package Details
Shipping Weight:
0.1 pounds
Package Size:
2 x 1.6 x 0.5 inches
Product Description
Hinge with friction torque for holding monitors, displays etc. in position. Cover available for clean appearance. Operating Temperature: -10 degree C - 50 degree C (14 degree F - 122 degree F). Shaft material stainless steel 303 with plain finish. Washer material phosphor bronze with polished finish. Spring washer material steel with nickel finish. Cover material ABS with silver finish.
