Fluke 77-4 Industrial Digital Multimeter with Large LCD Display, 50 Megaohm Resistance, 1000V AC/DC Voltage, 10A AC/DC Current, 99.99 kHz Frequency

Be the first to review this item


Specifications for this item
Overall Height
4.3  centimeters
Overall Width
9  centimeters
Part Number
Brand Name
Power Source Type
Number of Items
069060059519 , 632963648779
0069060059519 , 0632963648779
Overall Length
18.5  centimeters

This item is no longer available

This item is NOT eligible for "Free Standard Shipping on orders over $50.00" promotion. (Details)

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List

You can add a description later

Key Features

  • Large display; auto and manual ranging
  • Backlight for work in dim areas
  • Min/max to record signal fluctuations
  • Ergonomic overmolded housing with integrated probe holders
  • Free your hands with the optional TPAK magnetic hanger

Package Details

Shipping Weight: 1.35 pounds
Package Size: 10.7 x 5.8 x 3.3 inches

Product Description

The digital multimeter has the features needed to repair most electrical and electronic problems. This meter is simple to use and has significant improvements over Fluke's original 70 series with more measurement functions, conformance to the latest safety standards, and a much larger display that's easier to view. Wide 1000V measurement range. Average responding AC measurements. 0.3 percent accuracy. 10 Amps continuous (20A for 30 seconds). Frequency and capacitance. Resistance and continuity. Meets measurement category 1000V CAT III and category IV 600V safety standards. Voltage range: 6.000 to 1000V AC/DC. Current range: 60.00 mA to 10A AC/DC. Resistance range: 600 ohm to 50 megaohms. Capacitance: 9999 microfarad. Frequency range: 99.99Hz to 99.99kHz. Surge protection: 8 kV peak per IEC 61010. Fuse for mA inputs: 440 mA, 1000V fast fuse. Fuse for A inputs: 11A, 1000V fast fuse. Display: digital - 6000 counts, updates 4/sec, bar graph - 33 segments; updates 32/sec, frequency - 10000 counts, capacitance - 1000 counts. Altitude: operating - 2000 meters, storage - 12000 meters. Operating temperature: -10 to 50 degree C, storage - -40 to 60 degree C. Battery life: 400 hours typical (alkaline). Measures 18.5cm length by 9cm width by 4.3cm height.
