Fill-Rite 807CMK 3/4" Black Meter Kit for Pumps, NPT

Be the first to review this item

ASIN B003D7KGH4

Specifications for this item
Number of Items
1
Part Number
285-807CMK
Item Weight
0.1 pounds
UPC
089404190357 , 089404088302
Brand Name
Fill-Rite
EAN
0089404190357 , 0089404088302
UNSPSC Code
41112501

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Fri, Jul 25? Order in-stock items in the next 8 hrs 28 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Three-wheel register mechanical flow meter
  • Meters 5 to 20 gpm at pressures up to 50 psi
  • Aluminum body, buna-n seals, and stainless steel internal construction for corrosion resistance and outdoor use
  • 3/4" female NPT threaded connections
  • UL and CUL listed and displays CE marking

Package Details

Shipping Weight: 2.5 pounds
Package Size: 9.5 x 8.2 x 7.5 inches

Product Description

This Fill-Rite 807CMK three wheel register mechanical flow meter measures fluid flow up to 20 gallons per minute (gpm). This meter has 3/4" female National Pipe Taper (NPT) threaded inlet and outlet ports for inline connection, and the inlet and outlet manifolds rotate in 90 degree increments for flexibility in installation. The aluminum housing and buna-n seals are weatherproof and resist corrosion, and the meter has an operating temperature range of -10 to +130 degrees F. This flow meter is UL Listed (Underwriters Laboratories) to U.S. and Canadian safety standards and meets International Electrotechnical Commission (IEC) 60079 standards and displays the CE Marking. This mechanical four-wheel register flow meter is suitable for use in transferring diesel fuel, gasoline, kerosene, mineral spirits, Stoddard solvents, and heptane from mobile tanks in farming and construction applications.

Specifications
MeterMechanical three-wheel register
MaterialsAluminum housing, buna-n seals, stainless steel liner
Flow range5 to 20 gpm
Inlet/Outlet size3/4" NPT / 3/4" NPT
Metering accuracy+/- 1 percent
Maximum operating pressure50 psi
Cumulative storable total99,999.9
Specifications metUL and CUL Listed, IEC 60079, CE Marking

Tuthill Transfer Systems manufactures fluid transfer pumps and meters under the Fill-Rite brand. The company, founded in 1927, is headquartered in Fort Wayne, IN.

What's in the Box?
  • 807CMK mechanical flow meter
  • (2) 3/4" NPT fittings
