Click for larger image and other views Image is representative of the product family.

How can we improve our images or Product Specifications?

See all products in this Product Family

Fiberglass U-Channel, Gray, 7/8" Height, 3" Width, 60" Length, 1/4" Wall thickness

Be the first to review this item

ASIN B000FMUNXM

Product Specifications
Part Number
FGC-48/14-60
Overall Length
60  inches
Base Width
3  inches
Corner Style
Rounded
Dielectric Strength
200 volts/mil
Leg Length
7/8  inches
Length Tolerance
+0.000/-0.187  inches
Opacity
Opaque
Pkg Qty
1
Special Features
UV Resistant
Style Name
Equal Leg Length
Wall Thickness
1/4  inches
Specification for this product family (See all  products)
Item Shape
U-Channel
Tensile Strength Max
7000  PSI
Material Type
Fiberglass
Color Name
Gray
UNSPSC Code
30000000
Brand Name
Small Parts
System of Measurement
Inch
Item Density
0.07  Pounds per Cubic Inch

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Fri, Aug 1? Order in-stock items in the next 20 hrs 37 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • UV Resistant
  • Pound for Pound Stronger than Aluminum in the Length Wise Direction
  • Flammability is rated as self-extinguishing
  • Superior Corrosion Resistance
  • Transparent to Radio Waves and EMI/RF Transmissions

Package Details

Shipping Weight: 4.08 pounds
Package Size: 66.75 x 5 x 0.75 inches

Product Description

Channels are manufactured from isophthalic polyester resin and glass mat into a pultruded composite form.EXTREN - Series 525 profiles have a synthetic resin rich veil that contains a UV inhibitor and corrosion resistant surface. Flammability is rated as self-extinguishing. These profiles are non-magnetic and exhibit good electrical and thermal insulation properties that are transparent to radio waves and EMI/RFI transmissions.EXTREN is 30 Percent lighter and has 86 Percent of the yield strength of aluminum. It is pound for pound stronger than aluminum in the lengthwise direction of the profile. Temperatures above 150 F (65 C) are not recommended. These profiles can be easily fabricated with carpentry or metal working tools. Fasten with screws, bolts, and rivets, or join with adhesives.
