Dixon SCV800 Steel Check Valve, 1/2" NPT Female

Be the first to review this item

ASIN B0081LJCK4

Product Specifications
Part Number
SCV800
Number of Items
1
Size Name
1/2"
System of Measurement
Inch
Maximum Steam Pressure Description
Not Rated
Pressure Flow Rate
15  Gallons per Minute
Specification for this product family (See all  products)
Material Type
Steel
Maximum Pressure
5000  PSI
Style Name
Threaded
Connector Type
NPT Female
UNSPSC Code
40141600
Brand Name
Dixon Valve & Coupling

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Wed, Sep 3? Order in-stock items in the next 2 hrs 22 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Hydraulic fitting series C check valve
  • Provides free flow in one direction and dependable shutoff in the opposite direction
  • Maximum operating pressure is 5000 psi at 70 degree F
  • Cracking pressure: 5 psi
  • 1/2" Thread size

Package Details

Shipping Weight: 0.65 pounds
Package Size: 4.9 x 2.1 x 1.9 inches

Product Description

Hydraulic fitting series C check valve. Provides free flow in one direction and dependable shutoff in the opposite direction. Maximum operating pressure is 5000 psi at 70 degree F. Cracking pressure: 5 psi. 1/2" Thread size. 15 GPM free flow.
