Amprobe LM-120 Light Meter, Silicon Photodiode and Filter

Be the first to review this item

ASIN B005D2HVE8

Specifications for this item
Number of Items
1
Overall Height
35.6  millimeters
Overall Width
63.6  millimeters
Part Number
3052353
Temperature Range
-10/50  Degrees Celsius
UPC
095969419291
Brand Name
Amprobe
EAN
0095969419291
Measurement Accuracy
+/- 5 degrees_centigrade
UNSPSC Code
41115300
Display
Liquid Crystal Display (LCD) including Functions and Symbols
Special Features
Automatic, positive implied, negative polarity indication
Overall Length
183  millimeters

This item is no longer available

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Thu, Oct 2? Order in-stock items in the next 21 hrs 23 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Dual-scale meter measures visible light from fluorescent, metal halide, high-pressure sodium, and incandescent sources up to 200,000 lumens per square meter (lux) or 20,000 footcandles (fc), with auto-ranging and zeroing functionality
  • Silicon diode sensor and filter are designed for indoor use at altitudes below 2,000 meters
  • User-selectable auto or manual ranging, data hold freezes readings on the display, minimum and maximum recordings display the lowest and highest reading, zeroing capability resets the null point, and angled light cosine correction corrects for angled light
  • Complies with Japanese Industrial Standard (JIS) C1609:1993 and CNS 5119 general A-class specifications, and European Community Directives: 89/336/EEC (Electromagnetic Compatibility) and 73/23/EEC (Low Voltage) as amended by 93/68/EEC (CE Marking)
  • Powered by a 9V battery (included), and includes a 1.5-meter wire for positioning light sensor, and a protective sensor cap

Package Details

Shipping Weight: 0.7 pounds
Package Size: 11.4 x 6.2 x 2.8 inches

Product Description

The Amprobe LM-120 light meter measures up to 200,000 lumens per square meter (lux) or 20,000 footcandles (fc) of light output from fluorescent, metal halide, high-pressure sodium, and incandescent sources, has a silicon diode sensor and filter, and is designed for indoor operation at altitudes below 2,000 meters. The meter has manual ranging, a data hold feature to freeze readings on the display, minimum and maximum recordings to display the lowest and highest reading, zeroing capability to reset the null point, and angled light cosine correction to calculate the amount of light, regardless of the light's angle.

The meter is powered by a 9V battery (included) which has an average life of 200 hours. The sensor has a 1.5-meter wire for positioning the light sensor, and a protective sensor cap.

Specifications

Range 0 lux, 200 lux, 2,000 lux, 20,000 lux, 200,000 lux, 20 fc, 200 fc, 2,000 fc, 20,000 fc
Sampling rate 2.5 times per second for digital display
Accuracy + or - 3 percent (calibrated to standard incandescent lamp at 2,856 degrees K), + or - 6 percent for other visible light sources
Angle deviation from cosine, 30 degrees + or - 2 percent
Angle deviation from cosine, 60 degrees + or - 6 percent
Angle deviation from cosine, 80 degrees + or - 25 percent
Polarity Automatic, positive implied, negative polarity indication
Operating temperature 14 to 104 degrees F (-10 to 40 degrees C) at less than 80 percent relative humidity
Storage temperature 14 to 122 degrees F (-10 to 50 degrees C) at 0 to 70 percent relative humidity
Dimensions Base is 5.1 x 2.5 x 1.5 inches/130 x 63 x 38 mm, sensor is 3.2 x 2.2 x 1.1 inches/80 x 55 x 29 mm (H x W x D)
Weight .48 lb. (220 g) (including battery)
Standards Japanese Industrial Standard (JIS) C1609:1993 and CNS 5119 general A-class specifications, and European Community Directives: 89/336/EEC (Electromagnetic Compatibility) and 73/23/EEC (Low Voltage) as amended by 93/68/EEC (CE Marking)

H is height, the vertical distance from lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back.

Light meters measure luminous intensity, or light, and are commonly used in a wide range of industries and settings including photography, video filming, galleries, schools, laboratories, and greenhouses to help determine the brightness of light.

Amprobe manufactures electrical testing equipment for commercial, industrial, and home use. The company was founded in 1948 and is headquartered in Everett, WA.

What’s in the Box?

  • LM-120 light meter and sensor
  • 9V battery
  • Carrying case
  • Instructions
