Ample Scientific SM-Plus-13 Binocular Stereo Microscope, 1X and 3X Objectives Dual Magnification, WF10X/20 mm Eyepiece

Be the first to review this item

ASIN B003WOKPR4

Specifications for this item
Number of Items
1
Part Number
SM-Plus-13
Brand Name
Ample Scientific
Size Name
1X and 3X Objectives
List price:
$400.00
Price:
$238.22
You save:
$161.78 (40%)
Quantity:

In Stock (2)

This item ships for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Mon, Apr 21? Order in-stock items in the next 4 hrs 29 mins and choose One-Day Shipping at checkout.

  • Share

This item has already been added to

Update Quantity Cancel

Select a List Create New List


You can add a description later

Key Features

  • Stereo microscope for inspection and dissection creates three-dimensional images
  • Binocular viewing heads, inclined at 45 degrees for ergonomic comfort, ease eye strain and provide a more comprehensive view
  • Dual magnification options of 10X and 30X, with dual 1X and 3X objectives, and 10XD widefield eyepieces
  • Adjustable upper LED illumination reflects light off of the specimen with 30 LED bulbs, and adjustable lower LED illumination transmits light up through the specimen for enhanced visibility
  • One year limited warranty

Package Details

Shipping Weight: 11.2 pounds
Package Size: 17.5 x 15.9 x 11.4 inches

Product Description

The Ample Scientific SM-Plus-13 stereo microscope has binocular viewing heads, 30 LED bulbs for reflected and transmitted illumination, widefield 10XD eyepieces with a field number (FN) of 20 mm, and 1X and 3X objectives for total magnification of 10X and 30X. This microscope, with its stereo optical system, creates a three-dimensional image and enhances object or image resolution. It is commonly used by hobbyists, educators, and research professionals.

This microscope features binocular viewing heads to ease eye strain and provide a more comprehensive view. It has 55-75 mm interpupillary adjustment for individual eye spacing. Upper LED illumination reflects light off of the specimen, and lower LED illumination transmits light up through the specimen for enhanced visibility. Upper and lower illumination are each adjustable. The microscope has a dove-tail stand for durability that allows for one-handed operation. A handle fits easily in hand, and allows for safe and secure movement from one area to another. Stage clips hold the specimen in place.

Specifications

Total optical magnification 10X to 30X
Objective lenses 1X and 3X
Eyepieces 10XD widefield
Field number (FN) 20 mm
Viewing configuration Binocular
Illumination Upper and lower (adjustable) with 30 LED bulbs
Interpupillary adjustment 55-75 mm
Working distance 100 mm
Overall dimensions 62 x 39.5 x 48 cm/24.41 x 15.55 x 18.9 inches (H x W x D)
Weight 4.2 kg (9.26 lb.)
Illumination power source 85 to 265V
Warranty One year limited

*H is height, the vertical distance from the lowest to highest point; W is width, the horizontal distance from left to right; D is depth, the horizontal distance from front to back.

Microscopes are instruments used to enhance the resolution of an object or image. There are three types of microscopes: compound, stereo, or digital. Compound microscopes use a compound optical system with an objective lens and an eyepiece. Stereo microscopes show object depth in a three-dimensional image. Digital microscopes are used to display an image on a monitor, rather than looking through a lens. Microscopes can have monocular (one), binocular (two), or trinocular (three) eyepieces, with varying viewing abilities. A trinocular eyepiece is used to output digital images to an internal or external device such as a camera or monitor. Magnification ability refers to the size of an image. Resolution, also known as resolvant power, refers to the clarity of the image. The interaction between field of view (FOV), numerical aperture (NA), and working distance (WD) determines resolution. Microscopes can control magnification through a fixed focus, or through a range of adjustments. They can also use LED, fluorescent, and mirror light sources to help control viewing capabilities. Microscopes are widely used in education, lab research, biology, metallurgy, engineering, chemistry, manufacturing, and in the medical, forensic science, and veterinary industries.

Ample Scientific LLC manufactures laboratory equipment and supplies such as microscopes and centrifuges. Founded in 2009, and headquartered in Norcross, GA, Ample Scientific offers scientific equipment for research, educational, clinical and industrial applications.

What’s in the Box?

  • SM-Plus-13 microscope
  • Microscope head
  • 2 widefield, 10X eyepieces
  • Dust cover
  • Customer service card
  • Instructions
