Neoprene O-Ring, 70A Durometer, Round, Black

Be the first to review this item

Product Specifications
Material Type
Neoprene
Color Name
Black
Brand Name
Small Parts
Cross Section Shape
Round
Upper Temperature Range
275  Degrees Fahrenheit
Specification Met
AS568A
Hardness
70 A Durometer
UNSPSC Code
31410000
LowerTemperature Range
-65  Degrees Fahrenheit
System of Measurement
Inch

This item is no longer available

These items ship for FREE with 2-Day Shipping on orders over $50. (Details)

Want it delivered on Wed, Sep 3? Order in-stock items in the next 18 hrs 39 mins and choose One-Day Shipping at checkout.

  • Share
Currently showing 1-20 of 364 Next 20 »
Dash Size Nominal ID Nominal OD Nominal Width Actual ID Actual OD Actual Width Pkg Qty ASIN

The Amazon Standard Item Number (ASIN) uniquely identifies
the item in the AmazonSupply.com (and Amazon) catalog.

Available

If an item is currently out of stock, but has an estimated lead time, you can place an order now and we will ship it as soon as it is available.
You can also order more than we currently have in stock.
Read more about back orders in our help section.

Price
All All All All All All All All
Currently showing 1-20 of 364 Next 20 »
001 1/32" 3/32" 1/32" 0.029" 0.109" 0.04" 70 B0053UTV02 yes $6.55 Buy Options
002 3/64" 9/64" 3/64" 0.042" 0.142" 0.05" 75 B0053UTWLK yes $4.86 Buy Options
003 1/16" 3/16" 1/16" 0.056" 0.176" 0.06" 100 B0053UTXB4 yes $1.82 Buy Options
004 5/64" 13/64" 1/16" 0.07" 0.21" 0.07" 100 B0053UTXS2 yes $5.17 Buy Options
005 3/32" 7/32" 1/16" 0.101" 0.241" 0.07" 100 B0053UTY6I Temporarily out of stock. Order now and we'll deliver when available. $4.61 Buy Options
006 1/8" 1/4" 1/16" 0.114" 0.254" 0.07" 100 B0053UTYRM yes $4.72 Buy Options
007 5/32" 9/32" 1/16" 0.145" 0.285" 0.07" 100 B0053UTZXA yes $4.72 Buy Options
008 3/16" 5/16" 1/16" 0.176" 0.316" 0.07" 100 B0053UU1KG yes $5.10 Buy Options
009 7/32" 11/32" 1/16" 0.208" 0.348" 0.07" 100 B0053UU2IM yes $5.10 Buy Options
010 1/4" 3/8" 1/16" 0.239" 0.379" 0.07" 100 B0053UU3IQ yes $8.05 Buy Options
011 5/16" 7/16" 1/16" 0.301" 0.441" 0.07" 100 B0053UU4QC yes $4.25 Buy Options
012 3/8" 1/2" 1/16" 0.364" 0.504" 0.07" 100 B0053UU5R0 yes $5.85 Buy Options
013 7/16" 9/16" 1/16" 0.426" 0.566" 0.07" 100 B0053UU6RY yes $4.72 Buy Options
014 1/2" 5/8" 1/16" 0.489" 0.629" 0.07" 100 B0053UU7PA yes $4.91 Buy Options
015 9/16" 11/16" 1/16" 0.551" 0.691" 0.07" 100 B0053UU8S6 yes $6.49 Buy Options
016 5/8" 3/4" 1/16" 0.614" 0.754" 0.07" 100 B0053UUA6G yes $5.60 Buy Options
017 11/16" 13/16" 1/16" 0.676" 0.816" 0.07" 100 B0053UUBLK yes $8.47 Buy Options
018 3/4" 7/8" 1/16" 0.739" 0.879" 0.07" 100 B0053UUCGE yes $5.24 Buy Options
019 13/16" 15/16" 1/16" 0.801" 0.941" 0.07" 100 B0053UUDJU yes $11.11 Buy Options
020 7/8" 1" 1/16" 0.864" 1.004" 0.07" 100 B0053UUEDA yes $11.96 Buy Options

Key Features

  • Made of neoprene (polychloroprene) for use with a variety of fluids and gases from ammonia to Freon
  • Durometer (hardness) of 70A for resistance to penetration
  • Round cross-section to provide a seal between cylindrical overlapping surfaces
  • For use across a wide temperature range from -65 degrees F/-54 degrees C to 275 degrees F/135 degrees C
  • Meets standards defined by Aerospace Standard AS568A

Product Description

This black neoprene O-ring has a durometer of 70A, a round cross-section, and can be used across a wide temperature range (-65 degrees F/-54 degrees C to 275 degrees F/135 degrees C). Designed for use in a wide variety of sealing applications, this neoprene O-ring meets standards defined by Aerospace Standard AS568A, which is the Aerospace Size Standard for O-rings.

Neoprene (polychloroprene) can have a high tensile strength, and has abrasion, tear, and compression set resistance. It is generally fire resistant and compatible for use with ozone, sunlight, ammonia, Freon, and some hydrocarbons. It also had good adhesion to metal and is often used in metal to rubber bonding applications. Neoprene is vulnerable to ketones, acids, brake fluids and phosphate esters.

The durometer hardness of this neoprene O-ring is 70A. Durometers measure the hardness of a material and its resistance to permanent indentation. A higher durometer value indicates greater resistance to indentation. On a scale of 0 to 100, a value of 0 indicates that a sample was completely penetrated, while a value of 100 shows no indentation in the sample. The letter following the number identifies the shore scale, which is either shore A or D. Shore A is used for softer plastics, while shore D is used for harder plastics.

O-rings provide a pressure and fluid seal between cylindrically shaped, overlapping mating surfaces and are commonly seen in engines, faucets, flanges, valves, and various cylinders. They are circular in shape, with a round cross section, and a hole in the center, similar to a doughnut. O-rings are available in various AS568A dash sizes, which is the standardized sizing for O-rings, and defines the nominal inside diameter (ID), outer diameter (OD), and cross-sectional (CS) diameter of an O-ring.
